ASME CODE

ASME is a international code and standards, that’s referred to as standards, and practice of mechanical engineering. ASME is the globally recognized, trusted source of consensus standards since 1884.

General Knowledge Of ASTM A216

General Knowledge Of ASTM A216 This covers materials specification of carbon steel castings materials for Valves, all types of flanges, all types of fittings, or other pressure-containing parts for high-temperature service and suitable for assembly with other castings or wrought-steel parts by fusion welding. Within the ASTMA216 materials grade cover three grades, WCA, WCB, and […]

IMAGE OF ASME B16.11 FITTINGS

General knowledge of ASME B16.11

General knowledge of ASME B16.11 ASME B16.11 is a standard for the forged steel fittings of pipeline, in which cover all details like pressure ratings, dimensions, tolerances, marking and material requirements for socket weld and threaded fitting only. But for special requirements of forged fittings with special dimensions, threads, or counter bores may be made

Difference between ASME B16.5 VS ASME B16.47 VS API 605

What is ASME B16.5

ASME B16.5 Introductions This is an American standard for pipe flanges and flanges fitting to size NPS 1/2 through NPS 24 metric/inch, all temperature pressure, dimension, tolerance and materials, and its testing and methods of designate opening of pipes flanges and fittings cover within its. For example flange rating class designated as follow 150, 300,
